18 Wires Signal 2A Slip Ring Without Flange OD 12.5mm for Systems,
Product details
| Management number | 221455360 | Release Date | 2026/05/03 | List Price | US$27.22 | Model Number | 221455360 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The SNM012U-18, with 18 wires and compact 12.5mm body diameter, which we call our "mini", is our newest design and smallest physical package.uses fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates. SNM012U-18 DimensionsSNM012U-18 Specifications Contact Material Gold alloy brush,Gold plated rings Current Rating 2A, per ring, maximum Number of Circuits 18 Operating Speed 200 rpm* continuous Housing Material Engineering Plastics Lead Wire Awg28,color-coded, silver-plated Lead Lengths 250mm Voltage 210 VDC / 240 VAC Operating Temp. -40°C to 80°C Approx. 0.36 g.m (for reference ) Dielectric Strength 600V@50Hz between each circuit Insulation Resistance 600M@ 300VDC Noise 15 milliohms maximum tested @ 6 VDC, 40 milliamps when running @ 5 - 15 rpm Resistance to pull Radial 2KG,Axial 0.5KG Protection IP51
- 18 Wires Signal 2A Slip Ring Without Flange OD 12.5mm For Systems,
| Item Weight | 1.76 ounces |
|---|---|
| Manufacturer | KBLQLI |
| Item model number | KBLQLI |
| Package Dimensions | 0.39 x 0.39 x 0.39 inches |
